AOS UL7 V5 from AOS RC

Details

The AOS UL7 V5 is an ultra-light yet incredibly stiff 7-inch FPV drone frame that refines the groundbreaking arm design of its predecessor for even greater durability and stability. This enhanced structure delivers smooth, jello-free flights and tuning ease while offering stiffness comparable to most 5-inch frames. With an expansive 155-degree field of view, the AOS UL7 V5 ensures an immersive FPV experience, keeping propellers out of sight for unobstructed visuals. Designed to accommodate both DJI O3 and O4 systems, it allows pilots to capture stunning footage without interference. The frame also boasts unparalleled compatibility with a variety of flight electronics, featuring three stack positions that support 30.5x30.5mm, 25.5x25.5mm, and 20x20mm mounting, making it adaptable to both digital and analog FPV VTX setups. With its refined engineering, the AOS UL7 V5 provides a superior platform for long-range and freestyle enthusiasts looking for peak performance and customization.



Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the AOS UL7 V5 in particular but at least we know they do distribute AOS RC.

Wingspan: 312mm (12.3 in)
Length: 312mm (12.3 in)

Weight: 650 g (1.4 lbs)
  • Propeller Support: Up to 7" props
  • Anti-Vibration Technology: AOS X-Cell Anti-Vibration Mount
  • Stack Mounting Options: Three positions, supporting 30.5x30.5mm, 25.5x25.5mm, and 20x20mm
  • Field of View: 155° FOV with no props in view
  • Camera Compatibility: Fully DJI O3 compatible (soft mount + ND filters), supports 19-20mm cameras (hard or soft mounted)
  • Camera Cage: Reinforced 7075 aluminum construction
  • Motor Mounting: Supports ⌀16 - ⌀19mm motor mounting (compatible with all standard 7" motors)
  • Recommended motors: 2806.5 to 2808 (~1350KV for 6S ~1000KV for 8S)
  • Frame Weight: TBC grams (including hardware)
  • GoPro Mounting: 28x28mm M3 GoPro mounting pattern
  • Rear Standoff Spacing: 32mm
