Viper from Arrows RC

Details

Packing a jet-like 50mm 11-blade fan that’s spun up by a precision 2627 4500KV brushless motor, this 3S-fuelled pocket rocket will find favour in the hands of all who seek smooth, flowing aerobatics, a cloud punching performance and exceptional speed. But that’s not the half of it, the Viper is also a beautifully practical jet that exhibits exceptional low speed handling, is small enough to transport in one piece, retract free (hassle free) and enticingly budget-friendly. All this grace and performance from a 3S LiPo will almost certainly have you reassessing your EDF spend. So good is the Arrows Viper we’re convinced it’ll become a frequent flyer in your air fleet.

To minimize drag, increase flight time and guarantee the Viper's precision flight characteristics, Arrows RC designed a rigid single-piece wing structure and horizontal stabilizer. The lightweight airframe and esceptional aerodyncamics give the Arrows RC 50mm Viper excellent low speed handling and flight time uncharacteristic for small EDF jets of its size.

Features

  • Highly detailed pre-painted EPO foam airframe.
  • Glue- and screw-together assembly.
  • High-quality pre-installed hardware.
  • Outstanding power-to-weight ratio.
  • Secure easy-lift latch-retained canopy.
  • Three pre-installed high-quality digital servos.
  • 11-blade fan.

Pictures

Radio icons

(Click on the icon you want to download)
Horus & T16 OpenTx
Horus FrOs
Standard
Silhouette
X9D/X9D+/X9E
Spektrum IX12
Futaba 18MZ
Jeti DS-24

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Viper in particular but at least we know they do distribute Arrows RC.

Where to buy

Austria
Schweighofer AT
check web site
Ship to: International
Germany
Schweighofer GE
check web site
Ship to: Germany
France
miniplanes
check web site
Ship to: France
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
USA
Hobby Zone
check web site
Ship to: USA
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
United Kingdom
Arrow Models
check web site
Ship to: Europe

Winspan: 774mm (30.5 in)
Length: 696mm (27.4 in)

Weight: 470 g (16.6 oz)
  • Wingspan: 773.5mm (30.5in)
  • Length: 696mm (27.4in)
  • Flying Weight: Around 470g
  • CG (Center of Gravity): 60-70mm from leading edge
  • Power System: 2627-4500kV
  • Electronic Speed Control: 30A ESC
  • Propeller / EDF: 50mm 11 bladed EDF unit
  • Servos: 9 gram servo x 3
  • Landing Gear: None
  • Required Battery: 11.1V 1300mAh 30C

Variants

AH012P
Viper (White Red)
