Prime RES from CLM Pro

Details

CLM Pro has released a new model called Prime RES. The model is designed and produced according to FAI competition rules.
The model is designed and optimized to the last detail and it all comes together perfectly. Most importantly, when flying and competing, adjustments can be done quickly on the spot (ballast, hook etc.)
All parts are precisely laser-cut from balsa and aero plywood, all carefully selected high-quality materials.
Due to its aerodynamic design and excellent performance, it is very stable and is a joy to fly.

Prime RES is a model for competitions, made according to FAI rules.

As the name says, the "Prime" model has, among other things a few new features and details, which include:

* an adjustable hook: you can change the position of the hook (forward-backward) in the field in a second
* safety mechanism for the joint between wing segments - no more glueing with tape on joints and other improvisations: one click and the wing is attached
* ballast: integrated box in the pod, with a few reserve ballast modules, which can be changed in the field in literally two seconds without disassembling the model
* angled carbon wing joiners mean there is no complicated crafting of the box for the joiner in the wings. You receive everything ready in the kit.
* other details worked out to the last bit

Kit includes:

  • detailed drawing in color
  • detailed building manual with step-by-step images (coming soon)
  • CNC cut jig from styrofoam (underside of wings) for easier wing glueing
  • laser cut ribs and all other required parts
  • carbon tailboom
  • carbon tube for mainspar with kevlar wrapped where wing joiners go
  • carbon wing joiner and other carbon small parts
  • vitroplast safety mechanism for locking the wing segments in place
  • adjustable tow hook, including all necessary parts
  • rudder horns, u-nuts and various bolts for mounting
  • various magnets for the spoiler, ballast box and other
  • bowdens and controls for connecting moving surfaces

Pictures

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Prime RES in particular but at least we know they do distribute CLM Pro.

Where to buy

USA
Aloft Hobbies
check web site
Ship to: USA

Wingspan: 1960mm (77.2 in)
Length: 1256mm (49.4 in)

Weight: 430 g (15.2 oz)
Wingspan: 1960 mm 77.16"
Length: 1256 mm 49.44"
Wing area: 35 dm2  542 sq. in.
Airfoils: AG 24-26 mod AG 24-26 mod
Dihedral 11° 11°
Weight structure: 300 g 10.58 oz
Weight covered: 380 g 13.40 oz
Flying weight from: 430g 15.16
Control surfaces: RES RES

Variants

PRIME-RES-KIT
Prime RES (White Red)
