EYAS (FC Inside) from E SKY

Details

The latest version of the EYAS PNP FC INSIDE is a must-have for beginner pilots! This stunning yellow beauty has been updated and upgraded with flight control and assisted landing features, making every flight smooth and easy. But the innovations don't stop there. Pair it with the optional EPP floats (ESKY008328) for amphibious mastery. Effortless water takeoffs and landings are yours, with a responsive rudder system for nimble handling.

Assisted Landing Feature: When the aircraft is within 8 meters of the ground, with the throttle at the minimum, without any other input, the aircraft can automatically and stably land. The length of the landing runway depends on the altitude and speed when the landing is initiated (throttle reduced). The lower the altitude and speed, the shorter the landing distance. Experienced pilots can first control the pitch to bring the aircraft to around 1 meter above the ground, then level out and reduce the throttle, allowing for a perfect landing!

There are two modes available for the flight control. Lo Mode (Beginner Mode): Equipped with 6-axis self-stabilization control, making flight stress-free. The maximum tilt angle of the aircraft in all directions is limited to within 80°, combined with motion compensation function, ensuring the aircraft never flips over. Release the remote control stick, and the aircraft will automatically return to level flight, making it especially suitable for beginners and those who enjoy a relaxed, stress-free leisure flight. Hi Mode (Advanced Mode): Adopts 3-axis enhanced stabilization technology, allowing the aircraft to achieve 360° rolls in all directions. When the stick is released, the aircraft has a certain attitude stabilization assist capability, making it easier for the pilot to perform inverted, lateral, loop, and other 3D maneuvers.

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the EYAS (FC Inside) in particular but at least we know they do distribute E SKY.

Where to buy


Wingspan: 1100mm (43.3 in)
Length: 871mm (34.3 in)

Weight: 755 g (1.7 lbs)
  • Length: 871mm
  • Wingspan: 1100mm
  • ESC: 30A BEC 3A
  • Motor: 2306 2250Kv Brushless
  • Propeller: 6"
  • Servo: 8g x 4
  • Approx. Flying Time: 15 minutes
  • Flying Weight - Approx. 755g
  • Main Frame Material: EPO Foam
