Extra 330SC from E-flite

Details

The E-Flite Extra 330SC BP 3D combines the sturdy construction of a balsa/plywood airframe with the uninhibited 3D capability of a lightweight profile park flyer. It’s all made possible by its intelligently engineered, open structure design that keeps weight to a bare minimum while providing all the structural integrity of a real wooden airframe. This feather-light construction, combined with a high-output brushless motor, will provide spine-tingling 3D and freestyle performance that will let you really push the limits.

Features:

  • High-quality balsa and plywood construction
  • Light wing loading for excellent 3D performance
  • Hybrid-profile construction keeps weight to a minimum
  • Tapered-thickness airfoil optimized for both 3D and precision flight
  • Finished with UltraCote and UltraCote Lite covering
  • Stellar performance with the popular Park 450 motor
  • Factory-drilled control horn mounting holes
  • Factory-finished wheel pants and painted landing gear
  • Complete hardware package, plus motor mount included
  • Generously proportioned control surfaces
  • Steerable tail wheel for complete control
  • Airplane shown with recommended E-flite 2.0" aluminum spinner set (EFLSP200)—sold separately.

Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 942mm (37.1 in)
Length: 945mm (37.2 in)

Weight: 613 g (1.4 lbs)
  • Wingspan: 942mm (37.0 in)
  • Overall Length: 945mm (37.2 in)
  • Wing Area: 26.5 dm² (411 sq. in. )
  • Flying Weight: 587-613 g (20.7-21.6 oz)
  • Motor Size: Park 450 brushless outrunner (required)
  • Radio: 4+ channel radio system (required)
  • Servos: (4) sub-micro servos (required)
  • Trim Scheme Colors: UltraCote Transparent Red (U950), Transparent Clear (U964), Cub Yellow (U884), Sky Blue (U875), Silver (U881)
  • CG (center of gravity): 4.0 in (102mm) back from the leading edge of wing at wing sheeting
  • Wing Loading: 7.4 oz/sq ft (22.6 g/sq dm)
  • Prop Size: 12 x 6e (required)
  • Spinner Size: 2.0 in (51mm) (optional)
  • Speed Control : 30-amp brushless (required)
  • Recommended Battery: 11.1V 3S 1350mAh LiPo (required)
  • Control Throw (Ailerons): Low: 25mm up/down, 25% expo; High: 60mm up/down, 50% expo
  • Control Throw (Elevator): Low: 30mm up/down, 35% expo; High: 90mm up/down, 55% expo
  • Control Throw (Rudder): Low: 35mm right/left, 25% expo; High: 90mm right/left, 50% expo
