F-16 Thunderbirds 80mm from E-flite

Details

The E-flite® F-16 Thunderbirds 80mm EDF jet is the Smartest and most detailed high-performance model of the iconic airshow aircraft yet! Extra Scale details, including molded-in panel lines, simulated antennas, indicators, sensors and more, take realism to the next level. Functional Extra Scale features include LED navigation and landing lights, full-flying stabs, optional-use flaperons, sequenced gear doors plus the most scale-like retractable landing gear installed on an F-16 EDF model yet. Both versions include nine factory-installed digital, metal-geared servos, and with the ARF Plus version you can install the compatible receiver and an 80mm EDF power system of your choice — from another similar class model or using other compatible components.

The BNF® Basic version includes a V2 12-blade 80mm fan, high-power 2100Kv brushless inrunner motor, and a 100-amp Spektrum Avian™ Smart ESC to deliver fantastic performance with popular 6S 4000–7000mAh LiPo batteries – plus an incredible turbine-like sound. This efficient power system provides better performance and longer flight times than the 6S-compatible power systems used in similar-sized models powered by 90mm EDFs. It's also equipped with a factory-installed Spektrum™ AR8360T receiver featuring exclusive AS3X® and optional-use SAFE® Select technologies. When using compatible transmitters, the receiver and Smart ESC supply overall battery voltage, current, motor RPM and other telemetry data in real-time – with Smart and non-Smart batteries – along with optional-use motor reversing to shorten rollouts after landing and for other special ground handling capabilities. Constructed of molded EPO with plastic-capped strakes, hatch edges and openings to prevent damage to the fully-painted white plus red and blue finish during handling and when installing/removing batteries, this F-16 assembles without glue and can be ready to fly in much less time than other similar class models!

Features:

  • The Smartest and most detailed high-performance F-16 EDF (Electric Ducted Fan) jet model yet
  • Scale replica of the iconic aircraft flown by the U.S. Air Force Thunderbirds demonstration team
  • Fully painted white plus red and blue trim scheme with factory-applied stars and other markings
  • Extra Scale details including molded-in panel lines, simulated antennas, indicators, sensors and much more
  • Functional Extra Scale features including LED navigation and landing lights, full-flying stabs and more
  • V2 12-blade 80mm fan delivers excellent top speed and vertical performance plus turbine-like sound
  • Factory-installed, high-power 6S-compatible 2100Kv brushless inrunner motor and 100-amp ESC
  • 100-amp Spektrum Avian™ Smart ESC provides real-time battery voltage, motor RPM and other data – with Smart and non-Smart batteries – via compatible receivers and transmitters
  • Optional-use thrust reversing to help shorten rollout after landing and for other special ground handling capabilities
  • Fits a wide range of 6S batteries from 4000-7000mAh to deliver class-leading flight times and performance
  • Spektrum™ AR8360T receiver with full-range telemetry and industry-leading DSMX® technology
  • Easier to fly with innovative and optional-use SAFE® Select flight envelope protection
  • The unmatched stability and locked-in feel of exclusive AS3X® technology
  • Functional, optional-use flaperons pre-programmed for proper operation with AS3X and SAFE Select
  • Nine (9) factory-installed digital, metal-geared servos with ball-link equipped linkages
  • Electric retracts with scale-like painted, articulated and shock-absorbing struts
  • Sequenced, servo-operated nose and main gear doors with molded in details
  • Plastic capped strakes, hatch edges and opening for added durability to prevent damage and paint chipping
  • Two-piece wing with hands-free connections that bolts into place and a magnetically secured nose cone
  • No glue required for assembly and can be ready to fly in less time than it takes to charge a battery
  • Convenient top hatch with clear canopy, cockpit detail and a pilot figure
  • Optional simulated afterburner LED ring available separately
  • Extremely durable, fully molded EPO airframe

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the F-16 Thunderbirds 80mm in particular but at least we know they do distribute E-flite.

Where to buy

France
Flash RC
check web site
Ship to: Europe
Germany
Modellbau Berlinski
check web site
Ship to: International
Switzerland
ModellMarkt24
check web site
Ship to: Europe
Ireland
Model Heli Service
check web site
Ship to: Ireland
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
South Africa
Plane Crazy RC
check web site
Ship to: South Africa
Usa
Horizon Hobby USA
check web site
Ship to: USA
USA
AMain Hobbies
check web site
Ship to: USA
Australia
Daves Toys for Big Boys
check web site
Ship to: Australia
Belgium
Aerobertics
check web site
Ship to: Europe
Switzerland
Wieser Modellbau
check web site
Ship to: Switzerland
Germany
Voltmaster
check web site
Ship to: Europe
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
France
Turbines RC
check web site
Ship to: Worldwide
Austria
DMT
check web site
Ship to: Europe
France
Breizh Modelisme
check web site
Ship to: Europe
Austria
Lindinger ModellBau
check web site
Ship to: Europe
USA
Hobby Zone
check web site
Ship to: USA
USA
Grayson Hobby
check web site
Ship to: USA
France
Weymuller Modélisme
check web site
Ship to: France
France
Absolu Modélisme
check web site
Ship to: France
Spain
ACRO RC
check web site
Ship to: Europe
Ireland
Radio Controlled Shop
check web site
Ship to: Ireland
USA
Gator RC
check web site
Ship to: USA
USA
TOWER HOBBIES
check web site
Ship to: International
USA
Flite Test Store
check web site
Ship to: Worldwire
Germany
Horizon Hobby Europe
check web site
Ship to: Europe
Netherlands
RC webshop
check web site
Ship to: Europe
Austria
Slow Flyer
check web site
Ship to: Europe
USA
Atlanta Hobby
check web site
Ship to: USA
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
France
miniplanes
check web site
Ship to: France
Switzerland
Scamora
check web site
Ship to: Switzerland
United Kingdom
tjd Models
check web site
Ship to: United Kingdom

Wingspan: 1000mm (39.4 in)
Length: 1450mm (57.1 in)

Weight: 2727 g (6 lbs)
Power Type Electric
Wingspan 39.37" (1000 mm)
Material EPO
Fan Size 80mm EDF
Technology Smart, AS3X and SAFE
Motor Type Brushless
Minimum Required Radio 8 Channel
Product Weight 96 oz (2727 g) Without Battery
Connector Type IC5
Motor Size 3280-2100Kv
Product Length 57.09" (1450 mm)
