Opterra 1.2m from E-flite

Details

Lightweight construction and efficient aerodynamics make it possible for the E-flite® Opterra® 1.2m flying wing to deliver a wide range of capabilities that includes everything from sport flying and performing aerobatics, to soaring and beyond. It even gives you the ability to put yourself in the pilot's seat with optional FPV gear while also using a GoPro Session, RunCam HD or other similar class camera to record high-definition video at the same time (cameras and FPV gear sold separately).

The E-flite® Opterra® 1.2m flying wing is more compact than its 2-meter counterpart, yet it delivers added convenience, capability and flexibility through refined aerodynamics and an updated design that includes a number of great features. Its simplified three-piece airframe requires no tools or fasteners for assembly/disassembly with a convenient hands-free servo connection system and plug-in vertical fins. Enlarged elevons provide improved roll rate and control response, while a built-in keel with plastic cover makes launching easier and adds protection when landing. An improved motor mount design provides added durability and strength that’s perfectly matched to the brushless power system that’s compatible with 3S and 4S LiPo batteries right out of the box—no modifications or upgrades required. There are even channels molded into the wings that allow for installation of optional LED light strips, plus the standard and FPV camera noses can be swapped out without tools or fasteners.

Features :

  • Capable of sport flying, aerobatics, soaring, and more
  • 3S and 4S LiPo compatible brushless motor and ESC
  • Spektrum™ 6-channel receiver with industry-leading DSMX® technology
  • Stability and precision of AS3X® technology
  • Optional-use SAFE® Select flight envelope protection technology
  • Tool-free and fastener-free airframe assembly
  • Convenient hands-free servo connection system
  • Oversized elevons, offer excellent control response at any speed
  • Multiple vortex generator locations enhance slow speed stability and control
  • Includes standard and FPV camera noses
  • Integrated keel makes launching easier and adds landing protection
  • Molded-in LED channels for optional night flying capability
  • Lightweight and durable EPO foam construction with carbon-fiber support

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Opterra 1.2m in particular but at least we know they do distribute E-flite.

Where to buy

Usa
Horizon Hobby USA
check web site
Ship to: USA
Austria
Lindinger ModellBau
check web site
Ship to: Europe
Germany
Horizon Hobby Europe
check web site
Ship to: Europe
Ireland
Model Heli Service
check web site
Ship to: Ireland
France
Flash RC
check web site
Ship to: Europe
USA
TOWER HOBBIES
check web site
Ship to: International
Hungary
RC Hungary
check web site
Ship to: Hungary
Germany
Modellbau Berlinski
check web site
Ship to: International
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
Ireland
Radio Controlled Shop
check web site
Ship to: Ireland
Switzerland
Scamora
check web site
Ship to: Switzerland
Switzerland
Wieser Modellbau
check web site
Ship to: Switzerland
France
Absolu Modélisme
check web site
Ship to: France
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
Belgium
Aerobertics
check web site
Ship to: Europe
France
Weymuller Modélisme
check web site
Ship to: France
USA
Atlanta Hobby
check web site
Ship to: USA
USA
AMain Hobbies
check web site
Ship to: USA
USA
Hobby Zone
check web site
Ship to: USA
Netherlands
RC webshop
check web site
Ship to: Europe
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
Austria
DMT
check web site
Ship to: Europe
USA
Flite Test Store
check web site
Ship to: Worldwire
Switzerland
ModellMarkt24
check web site
Ship to: Europe
France
Turbines RC
check web site
Ship to: Worldwide
USA
Gator RC
check web site
Ship to: USA
United Kingdom
tjd Models
check web site
Ship to: United Kingdom
Germany
Voltmaster
check web site
Ship to: Europe
Spain
ACRO RC
check web site
Ship to: Europe

Wingspan: 1200mm (47.2 in)
Length: 525mm (20.7 in)

Weight: 980 g (2.2 lbs)
Flying Weight : 34.6 oz (980 g)
Length : 20.7 in (525mm)
Material : Foam/Carbon
Minimum Required Radio : Full-Range 5+ Channel DSMX®/DSM2® (sold separately)
Minimum Speed Control : 30A Brushless, 3S to 4S LiPo Compatible (installed)
Motor Size : 480-Size, 880Kv Brushless Outrunner (installed)
Recommended Motor Battery : 2200 to 3200mAh 3 to 4S LiPo with EC3 Connector (sold separately)
Servos : (2) 13-Gram Digital Micro (installed)
Wing Area : 437 sq in (28.2 sq dm)
Wingspan : 47.2 in (1200mm)

Variants

EFL11450
Opterra 1.2m (White)
