Viper 90mm from E-flite

Details

The E-flite® Viper 90mm EDF Jet is the Smartest, best handling, and easiest to fly large-scale model of the popular jet yet! It's a scale jet that flies smoothly and handles like a sport airplane — yet is also capable of incredible aerobatics and top speeds! But what truly sets it apart is how easy it is to take off, fly, and land, which makes it the BEST choice for a first large-scale jet model. Assembly is fast and simple, with no glue required. The lightweight, composite-reinforced EPO airframe is factory-finished in the now iconic Aircraft Studio Design trim scheme from the popular 70mm model. And the eight factory-installed digital, metal-geared servos with ball-link equipped linkages, plus control surfaces with pinned hinges, deliver crisp and precise control at every speed. Functional features include flaps, LED landing and navigation lights, and electric retracts with shock-absorbing, trailing-link struts on the nose and main gear so you can fly from grass and other surfaces with ease.

The BNF® Basic version includes a 12-blade 90mm fan, powerful 6S-compatible brushless inrunner motor, and a 130-amp Avian™ Smart ESC that all work together with the expertly optimized ducting to deliver an abundance of speed and thrust plus a turbine-like sound. With this power system, the Viper 90mm is capable of level flight tops speeds up to 120+ MPH and offers great vertical performance with 6S 4000mAh to 7000mAh batteries. It's also equipped with a factory-installed Spektrum™ AR637TA receiver featuring exclusive AS3X® and optional-use SAFE® Select technologies. When using compatible transmitters, the receiver and Smart ESC supply battery voltage, current, motor RPM and other telemetry data in real-time — along with optional-use motor reversing to shorten rollouts after landing and for other special ground handling capabilities. An ARF Plus version is also available for pilots who prefer to install their own choice of ducted fan unit, motor and ESC. Either way, for low-time to experienced jet pilots this model delivers a large-scale EDF experience unlike any other!

Features:

  • The Smartest, best handling and easiest to fly large scale Viper EDF (Electric Ducted Fan) model yet
  • A scale jet model with incredibly smooth sport airplane handling and amazing aerobatic capability
  • The best choice for a first large-scale EDF jet model because it's easy to take off, fly and land
  • Extremely wide performance envelope and speed range, capable of top speeds up to 120+ MPH
  • Functional features including LED navigation and landing lights, nose gear door and flaps
  • Reliable electric retracts with shock-absorbing, trailing-link struts for grass and other field operation
  • Expertly engineered and optimized ducting for incredibly efficient performance without "cheater" holes
  • 12-blade 90mm fan delivers excellent top speed and vertical performance plus turbine-like sound
  • Factory-installed, high-power 6S-compatible 3670-1950Kv brushless inrunner motor and 130-amp ESC
  • 130-amp Spektrum Avian™ Smart ESC provides real-time battery voltage, motor RPM and other data, plus reversing capabilities, via compatible receivers and transmitters
  • Fits a wide range of 6S batteries from 4000-7000mAh, or up to two 6S 3200-5000mAh batteries in parallel (or series for ARF Plus version), to deliver class-leading flight times and performance
  • Spektrum™ AR637TA receiver with full-range telemetry and industry-leading DSMX® technology
  • Easy to fly with innovative and optional-use SAFE® Select flight envelope protection
  • The unmatched stability and locked-in feel of exclusive AS3X® technology
  • Eight factory-installed digital, metal-geared servos with ball-link equipped linkages and control surfaces with pinned hinges
  • Removable/replaceable winglets, plastic capped nose and intake ducts for added durability
  • No glue required for assembly and can be ready to fly in less time than it takes to charge a battery
  • Two-piece wing with convenient V2 hands-free connections for easy storage and transport
  • Large and convenient top hatch with clear canopy, cockpit detail and pilot figure
  • Extremely durable, fully molded and composite-reinforced EPO airframe
  • Unique and highly visible trim scheme by Aircraft Studio Design

Pictures

Manual

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Viper 90mm in particular but at least we know they do distribute E-flite.

Where to buy

Usa
Horizon Hobby USA
check web site
Ship to: USA
Austria
Lindinger ModellBau
check web site
Ship to: Europe
Germany
Horizon Hobby Europe
check web site
Ship to: Europe
Ireland
Model Heli Service
check web site
Ship to: Ireland
France
Flash RC
check web site
Ship to: Europe
USA
TOWER HOBBIES
check web site
Ship to: International
Hungary
RC Hungary
check web site
Ship to: Hungary
Germany
Modellbau Berlinski
check web site
Ship to: International
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
Ireland
Radio Controlled Shop
check web site
Ship to: Ireland
Switzerland
Scamora
check web site
Ship to: Switzerland
Switzerland
Wieser Modellbau
check web site
Ship to: Switzerland
France
Absolu Modélisme
check web site
Ship to: France
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
Belgium
Aerobertics
check web site
Ship to: Europe
France
Weymuller Modélisme
check web site
Ship to: France
USA
Atlanta Hobby
check web site
Ship to: USA
USA
AMain Hobbies
check web site
Ship to: USA
USA
Hobby Zone
check web site
Ship to: USA
Netherlands
RC webshop
check web site
Ship to: Europe
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
Austria
DMT
check web site
Ship to: Europe
USA
Flite Test Store
check web site
Ship to: Worldwire
Switzerland
ModellMarkt24
check web site
Ship to: Europe
France
Turbines RC
check web site
Ship to: Europe
USA
Gator RC
check web site
Ship to: USA

Wingspan: 1400mm (55.1 in)
Length: 1281mm (50.4 in)

Weight: 3257 g (7.2 lbs)
Fan Size 90mm EDF
Power Type Electric
Material EPO
Motor Size 3670 - 1950Kv Brushless Inrunner (installed)
Product Length 1281 mm (50.43")
Product Weight 3257 g (115oz) w/Battery, 2522 g (89oz) w/o Battery
Wingspan 1400 mm (55.12")

Variants

EFL17750
Viper 90mm (White Red)
