Perregrine 76.5'' 70cc from EXTREME FLIGHT

Details

The Extreme Flight 70CC Peregrine is the big brother of our popular electric 53” Peregrine biplane. The goal of the Peregrine project was to produce a sharp-looking, fully-aerobatic biplane that is instantly comfortable for monoplane pilots. With our quick-latching wings and tail, setup at the field is remarkably fast and easy.

Powered with either a DA-70 or GP-76cc twin cylinder gas engine, the Peregrine is happy in sport/precision, 3D, or XA flying modes. If you want to go 12S electric power, the Peregrine has an integrated battery hatch for easy access.

The Peregrine is a very complete kit including: pilot figure, cockpit floor and dashboard, standard foil wing bags, carbon fiber landing gear and tailwheel, carbon wing and stab tubes, and all competition-grade hardware (including Du-Bro ball links.) You’ll save time during assembly with factory pre-hinged and gap-sealed control surfaces, pre-installed control horns and genuine Ultracote covering. We go the extra mile with gas cooling baffles, a two-piece cowl, a clear template for cutting exhaust holes, all-quick-latching wings, struts, canopy and battery hatch and more!

The Peregrine features a unique flow-through cowl system with pre-fabricated fiberglass in-and-out cooling ducts to force cooling air directly over the cylinder heads of your engine. If you are using electric power, you can lightly modify the gas cooling ducts for your electric system, or you can use these 3D printing files to create custom-fit electric cooling ducts.

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1940mm (76.4 in)
Length: 2175mm (85.6 in)

Weight: 10880 g (24 lbs)
  • Wingspan: 1940 mm (76.5")
  • Control: Ailerons, Elevator, Motor Powered, Rudder
  • Length: 2175 mm (85.7")
  • Fuselage:  Wood
  • Wings: Wood
  • Weight: 9.5 to 10.8kg (21-24 lbs)
  • Spinner: 5.0"
  • Wing Area: 124.58 dm² (1931 sq. in)
  • Rec. engine: Scorpion A-6528-200kv / 60-70cc
  • Rec. Battery: 12S/5000-5500mAh LiXX
  • Version: ARF - ALMOST READY TO FLY
  • Drive Type:    Electric & Combustion
