Turbo Bushmaster 84" from EXTREME FLIGHT

Details

This is the updated 84" Turbo Bushmaster CNC by Extreme Flight's Legacy Aviation! Based on the venerable Turbo Beaver, this Cody Wojcik design is quite simply one of the most popular planes we've produced. The updated 84" Bushmaster features more access and ease of assembly with the removable windscreen via the CNC latches.  Field assembly is now minimized with CNC quick latches to secure the two piece wing and a single bolt to attach/remove the strut.

All control surfaces are pushrod driven with short linkages and use ball links for slop free actuation with no binding.  Expertly painted fiberglass cowl and mounting hardware matching the 3 gorgeous high visibility Ultracote color schemes are the finishing touches that will make this an airplane that you will be proud to show up at the flying field with.

As with all of our aircraft the 84" Turbo Bushmaster incorporates carbon fiber and G10 composites into the structure of the airframe, resulting in a lightweight, yet twist free structure. Big and light, the Bushmaster is as gentle and forgiving as any trainer we've ever flown, making for a very enjoyable and relaxing flying experience. Flip the rate switches and the model transforms into an extremely capable aerobat!

Experiment with the various flap mixes that are possible with double beveled ailerons and flaps and you open up a whole new envelope of high lift/high drag maneuvers. Although the Bushmaster spans 84" typical AUW is below 8 pounds! You can imagine how "floaty" a model this size is at that weight!  Couple the 84" Bushmaster with the T-Motor AM600 power combo and be prepared for unlimited vertical performance!

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 2133mm (84 in)
Length: 1615mm (63.6 in)

Weight: 3850 g (8.5 lbs)
  • Wingspan: 2133 mm (84 in)
  • Fuselage Length: 1615 mm (63.6 in)
  • Wing Area: 26.6 dm² (1224.5 sq in)
  • Weight (Ready to Fly): 3,4 kg–3,9 kg (7.5–8.5 lbs - depending on battery)
  • Motor: T-Motor AM600
  • ESC: T-Motor AM116
  • Propeller: 16×8
  • Battery: 6S 3300–4000mAh LiPo
  • Spinner: EF Cyclone 63 mm (Included)
  • Servos Required: 6 metal-geared mini servos (e.g., Savox SV1250MG, SV1261MG, Theta 989)
  • Servo Arms:
    • (5) 1.25" EF servo arms tapped for 2mm (ailerons, flaps, elevator)
    • (1) 3" EF servo arm tapped for 2mm (rudder)
    • Control Throws (suggested):
  • Aileron:
    • Low: ±20° (18–20% expo)
    • High: +38°/−37° (50–60% expo)
  • Elevator:
    • Low: ±10–12° (18–20% expo)
    • High/3D: ±45–50° (50–60% expo)
  • Rudder:
    • Low: ±20° (50–60% expo)
    • High: 45°+ (60–80% expo)
  • Center of Gravity: Balance on main wing tube for maiden flight
  • Wing Tube: 20×800 mm
  • Incidence & Thrust Settings:
    • Main Wing: +0.5°
    • Stabilizer: 0°
    • Right Thrust: 2.5°
    • Up/Down Thrust: 0°
  • Radio System Required: Modern 7+ channel computer radio
  • Recommended Extensions (when using MPX plug):
    • (2) 12" 22–28 AWG (outer ailerons)
    • (1) 24" 22–28 AWG (elevator)
