Hawker Sea Fury from FlightLine RC

Details

The Hawker Sea Fury was the last piston engine driven carrier based fighter in British history. Although the Sea Fury did not participate in the Second World War, the aircraft earned distinction operating from British and Australian carriers during the Korean War where its performance and resilience earned the Sea Fury its place in aviation history. The Sea Fury also served across the world in the service of Australia, Canada, the Netherlands, Burma, West Germany, and many other nations. Following its retirement from military service, the Sea Fury continues to amaze audiences in racing competitions and air shows worldwide.

FlightLine RC presents its Hawker Sea Fury FB.11 in the livery of a VX730/109/K of the 805 NAS, Korea 1951. Constructed using EPO foam, this model uses carbon tubes and plastic parts to reinforce the removable wings and control surfaces. Screws allow the wing and elevator to be easily removed. The four panel split flaps are reinforced with lite plywood, and the fuel tanks can be glued on at the owner's discretion. To maximize performance efficiency, FlightLine RC's Sea Fury features a four bladed propeller and 580kv motor to achieve satisfying scale performance at 135kph/83mph speeds. An optional two bladed power system (sold separately) can be purchased to reach 150kph/93mph level speeds on the same 4s 14.8v battery.

Features:

  • Removable main wing/elevator for easy transport
  • High power motor for speeds up to 135kph/83mph
  • Intuitive internal structural design for optimized cooling of all electronics in the fuselage from the nose to the tail
  • Large cabin space for easy placement of the battery and radio equipment
  • Built-in flat spot near the CG for optimal placement of a gyro (optional, sold separately)
  • Improved spinner and propeller mounting design to enable better balance
  • Optional upgrade complete nylon hinge set included in each box for free
  • Tall foam rubber 65mm diameter main wheels and additional forward rake angle for operating on short grass runways
  • Electric retractable landing gear with metal trunions, metal reinforcement plate and 4mm steel wire struts
  • Optional two bladed propeller Sport Power System (sold separately) to achieve speeds up to 155kph/96mph

Pictures and description from MotionRC

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Hawker Sea Fury in particular but at least we know they do distribute FlightLine RC.

Wingspan: 1200mm (47.2 in)
Length: 1085mm (42.7 in)

Weight: 1550 g (3.4 lbs)
Wingspan 1200mm / 47in
Length 1085mm / 42.7in
Flying Weight 1550g / 54oz
CG (Center of Gravity) 80mm from the leading edge of the wing at the root
Power System 3748-580Kv Brushless Outrunner Motor (Stock scale power system)
3648-880Kv Brushless Outrunner Motor (Optional sport power system)
Electronic Speed Control 60A Brushless with XT60 connector
Propeller / EDF 12x7 4 Blade Propeller / 12x8 2 Blade Propeller High Performance Version (optional)
Required Battery 4 Cell 14.8V 3600mAh to 4000mAh LiPo battery with XT60 Connector
