Vulcan High-Performance from Freewing Model

Details

Freewing's latest sport jet delivers the widest flight envelope in its class. With its tuned wing loading and power system, enjoy flying with the precision of a sport jet, the ease of a trainer, and the speed of a powerhouse. Our team developed the Vulcan 70 to offer both an approachable trainer for first time EDF jet pilots, while still offering veteran Avanti or Stinger 90 pilots an aircraft that brings something new to the hangar.

Envisioned as a multi-role aircraft for both novice and expert pilots alike, the Vulcan 70 is optimized to deliver the best all-around performance in an economical and everyday flier. Fine tune every maneuver in the book with the Vulcan 70's precise handling, high power 6S inrunner powerplant, grass-friendly landing gear, and a high visibility scheme that stands out on the flight line at your local RC flying field.

Features:

  • Hybrid metal gear servos throughout
  • 115mph airspeed on the stock 2957-2210Kv brushless inrunner and 6S 4000mAh battery
  • Optimized ducting that eliminates the need for a cheater hole
  • Electric retracts and trailing link suspension struts for grass operation
  • Removable wings with quick disconnect plug
  • 1050mm wingspan and 1180mm length
  • Magnetic removable nose cone with plastic cap for durability

Pictures and description from Motion RC

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1050mm (41.3 in)
Length: 1180mm (46.5 in)

Weight: 1380 g (3 lbs)
Wingspan 1050mm / 41.3in
Length 1180mm / 46.4in
Empty Weight 1380g / 48.6oz
CG (Center of Gravity) 98mm from the leading edge of the wing's root
Power System 2957-2210Kv brushless motor (installed)
Electronic Speed Control 70A (installed)
Propeller / EDF 70mm 12-Blade EDF (included)
Servos 9g digital hybrid gear standard with 600mm lead: left aileron, right aileron, left flap, right flap, rudder
9g digital hybrid gear standard with 800mm lead: left elevator
9g digital hybrid gear reverse with 800mm lead: right elevator
9g digital hybrid gear standard with 400mm lead: nose gear steering
Landing Gear Electric retractable full suspension struts, including mid-travel trailing link main struts (included)
Required Battery 6 Cell 22.2V 3300 - 5000mAh LiPo battery with EC5 Connector (required)
Material EPO Foam
