Sbach 342 from Skynetic

Details

The Skynetic Sbach 342 EPP 3D is a 3D flyer made of durable, lightweight and extremely thick EPP foam for rigidity that can help you perform show-stopping indoor 3D maneuvers with ease. The gear are easily removable for transport and/or flying preference. Can be flown both indoors in a large area like a gym or outside. With a streamlined and aerodynamic profile, the Sbach 342 EPP 3D is tailor-made for countless hours of exhilarating, crash-resistant flying fun!

Features:

Slick, streamlined and aerodynamic profile with sharp red and black livery
Extremely thick and nearly indestructible EPP foam for a high level of crash resistance
Powerful AS2212 KV1250 Brushless motor for a wide flight performance envelope

Pictures

Manual

If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Sbach 342 in particular but at least we know they do distribute Skynetic.

Where to buy

Netherlands
Motion RC B.V.
check web site
Ship to: Europe

USA
Motion RC LLC
check web site
Ship to: USA

Wingspan: 900mm (35.4 in)
	Length: 990mm (39 in)
Weight: 560 g (1.2 lbs)

See Specs & Tech Details

Wingspan	900mm / 35.4in
Length	990mm / 39.0in
Weight	560g / 19.75oz
CG (Center of Gravity)	95 - 100mm from the leading edge of the wing at the root
Power System	AS2212 Kv1250 Brushless motor (installed)
Electronic Speed Control	30-amp brushless ESC with XT60 connector (installed)
Propeller / EDF	Electric (included)
Servos	4x 9g standard servo for ailerons, rudder, elevator - SKY6005-002
Landing Gear	Fixed
Required Battery	3 Cell 11.1V 1100 - 1200mAh LiPo battery with XT60 Connector (required)
Required Radio	4+ Channel (required)
Ailerons	Yes
Elevator	Yes
Rudder	Yes
Material	EPP Foam
