Avanti V3 from fms

Details

Developed by a Sino-Italian team of pilots and engineers, the FMS Avanti is at the pinnacle of model aviation. The sleek and attractive design from the Sebart team, combined with FMS’ innovative and advanced production methods promises excellent performance from a true head-turning aircraft.

True to the FMS spirit, the 70mm Avanti V3 was evaluated from nose to tail with no detail overlooked. Retaining the plug-type wiring harness, screw-together assembly, all-terrain tires, plastic and carbon fiber components for added airframe rigidity and an oversized battery compartment to suit most battery sizes.

Features

  • improved EDF structure for added efficiency
  • An updated 3060 KV1900 motor for added thrust to weight ratio.
  • Upgraded ESC: Hobbywing OEM 80A ESC with 5A BEC for improved reliability and performance
  • Improved wing connector: banana plug improved to a soft connector type- for added reliability.
  • Improved landing gear: redesigned kneel-type shock absorbing landing gear strut.
  • Attractive golden trim scheme
  • Added navigation lights
  • Durable EPO material
  • 70mm 12 bladed EDF, 3060 KV1900 motor, Hobbywing OEM 80A ESC, 9g metal servo
  • Electronic retracts with stall-protection
  • CNC kneel-type shock absorbing landing gear
  • Oversized battery compartment
  • Screw-together assembly
  • Soft electronic wing connector
  • Latch type cockpit
  • Preinstalled ball link connector for increased throw and precision
  • Large tires for all terrain operations

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Avanti V3 in particular but at least we know they do distribute fms.

Where to buy

Ireland
Model Heli Service
check web site
Ship to: Ireland
France
Flash RC
check web site
Ship to: Europe
France
interModel
check web site
Ship to: France
USA
TOWER HOBBIES
check web site
Ship to: International
Usa
Horizon Hobby USA
check web site
Ship to: USA
Germany
Modellbau Berlinski
check web site
Ship to: International
Switzerland
Grischa Modellbau
check web site
Ship to: Switzerland
Switzerland
Wieser Modellbau
check web site
Ship to: Switzerland
France
Absolu Modélisme
check web site
Ship to: France
United Kingdom
Als Hobbies
check web site
Ship to: United Kingdom
Belgium
Aerobertics
check web site
Ship to: Europe
USA
Atlanta Hobby
check web site
Ship to: USA
USA
AMain Hobbies
check web site
Ship to: USA
USA
Hobby Zone
check web site
Ship to: USA
USA
Graves RC
check web site
Ship to: USA
Netherlands
RC webshop
check web site
Ship to: Europe
United Kingdom
Model Shop Leeds
check web site
Ship to: United Kingdom
Austria
DMT
check web site
Ship to: Europe
United Kingdom
Arrow Models
check web site
Ship to: Europe
USA
Flite Test Store
check web site
Ship to: Worldwire
France
Turbines RC
check web site
Ship to: Worldwide
United Kingdom
tjd Models
check web site
Ship to: United Kingdom
Germany
Voltmaster
check web site
Ship to: Europe
France
miniplanes
check web site
Ship to: France

Wingspan: 900mm (35.4 in)
Length: 1050mm (41.3 in)

Weight: 1850 g (4.1 lbs)
Wingspan 900mm (35.4in)
Overall Length 1050mm (41.3in)
Flying Weight Around 1850g
Motor Size 3060 1900Kv
ESC 80A with 5A BEC
Servo 9g metal digital Servo x 8
Radio 6 Channel
CG (center of gravity) 100-105mm
Recommended Battery Li-Po 22.2V 3300mAh 35C
Aileron Yes
Elevator Yes
Rudder Yes
Flaps Yes
Retracts No
Assembly Time 15 minutes
Material Durable EPO
Package Options PNP

Variants

FMM127P
Avanti V3 (Blue Red White Gold)
