T-Rex TN70 from Align

Details

This is the Allign T-Rex TN70 Super Combo Nitro Helicopter Kit. This high end nitro helicopter kit is loaded with updated features that elevate this kit to a higher level of performance and reliability. Equipped with CNC machined metal reinforcement plate and brace for added protection, heat dissipation and improved reinforcement to the mainframe and updated tail belt drive pulley design that effectively reduces vibration and tooth sweeping! In addition, an updated swashplate with an improved mounting rod design that provides supreme reliability and stability while preventing the detachment of the rods during extreme maneuvers.

The body design was engineered to be narrow and efficiently decrease gear abrasion and frame deformation during flights with a lightweight and impact resistant landing skid to increase the overall durability of the T-Rex TN70. Additionally, the Anti-rotation bracket is constructed from metal and wear resistant composite to effectively reduce friction resistance and have better precise servo movement. Another great updated feature is the steel alloy clutch liner that adds durability and increases heat dissipation. Also, the rotor head was updated to a CNC machined LCG (Low Center of Gravity) lightweight aluminum design, paired with a CNC carbon steel grinding spindle to provide excellent stability and flight control! Get the T-Rex TN70 and experience the top level of quality and performance with this powerful Chopper!

Features:

  • Fast and remarkable carbon fiber tail boom design
  • High performance Allign 105 pipe that increases the overall power, reduces the noise and increase flights duration with fuel saving characteristics
  • Updated tail belt drive pulley design that effectively reduces vibration and tooth sweeping
  • CNC machined metal reinforcement plate and brace for added protection, heat dissipation and improved reinforcement to the mainframe
  • Updated CNC machined LCG (Low Center of Gravity) lightweight aluminum rotor head paired with CNC carbon steel grinding spindle to provide excellent stability and flight control
  • Engineered narrow body design that efficiently decreases gear abrasion and frame deformation during flights and increases overall durability
  • Updated lightweight body design with quick and continuous power response
  • Updated lightweight (120g) canopy
  • Guide R angle frame design that effectively reduces the hardness and anti-deformation ability
  • Updated lightweight and impact resistant landing skid
  • More stable widened structure
  • Press buckle canopy mounting bolt design
  • Anti-rotation bracket constructed from metal and wear resistant composite to effectively reduce friction resistance and have more precise servo movement
  • Updated super durable CNC machined Helical thread main drive (107T) gear
  • An integrated motor mounting bracket for more efficient heat dissipation
  • Properly tightened tail belt through the pulley arm to make maintenance more convenient and the flight more smooth
  • Updated torque tube umbrella gear made of industrial grade fiber composite with high rigidity and wear resistance features
  • Updated steel alloy clutch liner for added durability and heat dissipation

Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1543mm (60.7 in)
Length: 1352mm (53.2 in)

Weight: 4110 g (9.1 lbs)
  • Engine: 105 Nitro
  • Length: 1352mm
  • Width: 202mm
  • Height: 397mm
  • Main Blade Length: 690mm
  • Main Rotor Diameter: 1543mm
  • Tail Length: 105mm
  • Tail Rotor Diameter: 279mm
  • Fuel Tank Capacity: 630cc
  • Weight: Approx. 4110g
  • Main Drive Gear: 107T
  • Autorotation Tail Drive Gear: 102T
  • Tail Drive Gear: 23T
  • Gear Ratio: 7.43 : 1 : 4.23
