F-86 Sabre from Arrows RC

Details

The North American F-86 Sabre was the first US fighter aircraft designed using the German research that showed a 35 degree thin swept wing gave superior transonic performance. The Sabre was the equal of its well-known Korean War opponent, the Mig-15. It was the highest production US jet fighter ever made, with total production of 9860 units. It was manufactured in many variants, and the Navy FJ fighter was a modified version suited for carrier operations. It was the first fighter equipped with air-to-air missiles, and later versions were supersonic in a dive. All in all, it is a classic.

While Arrows has introduced a number of EDF jets, from the hand tossed Viper to the high-end MiG-29 and F-15, our engineering team began with the Marlin 64mm EDF, still the best EDF trainer made. The F-86 is the successor to the Marlin with fixed gear for strength and the same full 5-channel performance with flaps. The plane has excellent performance and agility at high speed and stability during landings.

The smooth 12-blade 64mm fan sounds more realistic than older 5-blade 64mm units others use. Because of the more powerful 2840-3150KV motor and a 40 amp ESC, this plane is capable of top performance even though it is larger than other 64mm F-86's, with maneuvers such as rolling, diving, looping, and inverted flight. The quick release landing gear allow for fast transition from ground take-off to hand lauch and facilitates easy transport.

The EPO foam is tough and at 820mm length and 860mm wingspan, it is a perfect 1/10 scale of the original full-scale plane. The contours, panel lines, and markings are highly accurate and realistic. The special water-based paint has a very realistic look. Assembly is fast and simple using only a few screws.

Get ready for a new experience in EDF's with the Arrows 64mm F-86 Sabre.

Features:

  • 12-bladed 64mm EDF, 2840-3150KV motor, 40A ESC, 9g servos
  • Highly realistic scale components: panel lines, functional flaps, dual drop tanks
  • Steerable nose gear for enhanced ground maneuverability
  • High-quality rubber tires
  • Preinstalled ball-linked linkages for precise surface movements
  • Carbon reinforced airframe
  • Fantastic low-speed performance and aerobatic capabilities

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 860mm (33.9 in)
Length: 820mm (32.3 in)

Weight: 1050 g (2.3 lbs)
  • Wing Area: 15.2dm² (235in²)
  • Wing Loading: 69g/dm² (0.15oz/in²)
  • Wingspan: 860mm (33.8in)
  • Length: 820mm (32.3in)
  • Flying Weight: 1050 g
  • CG (Center of Gravity): 130-140mm from the leading edge
  • Power System: 2840-KV3150
  • Electronic Speed Control: 40A (XT60)
  • Servos: 9g servo x 8
  • Landing Gear: Fixed
  • Required Battery: 4S 2200-2600mAh 35C XT60 Connector
  • Required Radio: Minimum 5 Channel transmitter and receiver required
