Banshee from Freewing Model

Details

The Freewing Banshee 64mm EDF Jet is the perfect introductory model for those seeking to break into the thrilling world of foam Electric-Ducted Fan jets. Made with industry-standard and durable EPO foam, the Banshee comes with a 12-blade EDF with a robust 2840-2850Kv outrunner brushless motor for captivating aerial adventures.

The Banshee's streamlined shape penetrates through the skies with minimal resistance while the 4s power system delivers an exhilarating thrust-to-weight ratio. The Banshee’s modular structural design uses plastic joints and screws to facilitate simple assembly, maintenance, and repair, a welcomed departure from the tedious and adhesive assembly of models from years past.

Enjoy the Banshee’s low wing loading for increased performance at lower speeds. With the installed flaps the jet can handle slower landings and shorter takeoffs with ease. The ESC has a reverse thrust function that slows the jet upon landing, dramatically reducing the landing rollout. If you do not wish to utilize the fixed landing gear, the Banshee excels as a capable hand-tosser/belly lander. Take to the skies with this excellent jet that both novice and experienced pilots alike will equally enjoy.

Features:

  • 40 Amp V2 Electronic Speed Control with reverse thrust functionality
  • Flaps are included for slower flight, landings and quicker takeoffs
  • All-New ESC with Thrust Reverse Function
  • Comes with 12-Blade EDF with 2840-2850Kv Outrunner Brushless Motor
  • 4S LiPo capability for High Performance Flight (not included)
  • Scale details including painted pilot and cockpit, panel lines and landing gear
  • 8x 9g digital servos come pre-installed

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 900mm (35.4 in)
Length: 950mm (37.4 in)

Weight: 780 g (1.7 lbs)
Wingspan 900mm / 35.4in
Length 950mm / 37.4in
Weight 780g (without battery)
CG (Center of Gravity) 64mm from the leading edge of the wing root
Power System 2840-2850Kv Outrunner Brushless Motor
Speed Control 40A, internal SBEC with XT60 Connector
Propeller / EDF 64mm 12-Blade EDF
Servos
  • 9g digital reverse gear with 300mm lead : nose steering - MD31093R-300
  • 9g digital standard metal gear with 400mm lead : ailerons, flaps - MD31092-400
  • 9g digital standard metal gear with 600mm lead : left elevator, rudder - MD31092-600
  • 9g digital reverse gear with 600mm lead : right elevator
Landing Gear Fixed main landing gear, steerable nose gear.
Required Battery 4S 14.8V 2200mAh with XT60 Connector
Hinge Type Nylon hinges on all control surfaces
Material EPO Foam
