PT-17 from Maxford USA

Details

The PT-17 is a biplane that was used as a military trainer by the US Army Air Corps during the 1930s and it served throughout WWII. The PT-17 is also widely known as the Stearman, Boeing Stearman, Boeing Model 75, or the Kaydet. At least 9,783 were built and thousands of surplus PT-17s were sold on the civil market after the conflict.

This almost ready to fly radio control version of the PT-17 is based on the aircraft that is owned by John Mohr, who very kindly sent us many detailed pictures of his personal aircraft. We also acknowledge and thank Jay Smith, editor or Model Aviation, for his help and advice on this project.

V1.1 improvements to Maxford USA’s ARF PT-17 Stearman: Landing gear fairings are a new 2-piece ‘split’ design; these fairings can now be replaced separately from the aluminum main landing gear strut; Wing wires have been upgraded to steel cables; windshields are now thicker and have a darker-color for the simulated frames; tail wheel strut is now simpler to install; wing tips have been strengthened; and wood has been added to the cockpit hatches to simplify installing optional pilot figures. NOTE: The vertical stabilizer’s alignment to the aft turtledeck (the top of the convex surface of the fuselage behind the rear cockpit) was improved earlier, as a running-change to V1.

Features:

  • The fuselage, wings and empennage are factory-built from laser-cut balsa and light plywood.
  • The ‘oversized’ magnetic hatch is big enough for easy access to all fuselage-mounted components.
  • A dummy radial engine and a pair of scale windshields are included.
  • Plastic leggings cover the aluminum main landing gear for true-to-scale looks; wheels have treaded tires.
  • The included steerable tail wheel also has a true-to-scale appearance.

Fly RC Magazine Review

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1270mm (50 in)
Length: 940mm (37 in)

Weight: 970 g (2.1 lbs)
  • Wingspan: 1270 mm (50")
  • Overall length: 940 mm (37")
  • ARF weight: 970 g (2 lbs 2 oz)
  • Prop: 11x6, 11x7
  • Motor Required: 400W brushless motor or .30~.40 size 2C glow engine
  • Battery Required: 3~4S 2100 mAh Li-Po
  • Radio Required: 4ch 4 mini servos
