AcreoBee65 BLV4 from NewBeeDrone

Details

This drone has been carefully crafted using only newbeedrone parts. It is important to note that any use of non-compatible parts from other brands may result in technical difficulties. Additionally, should you choose to modify the drone, it is crucial that you assume full responsibility for any resulting issues. It is not advisable to proceed with modifications without the necessary knowledge and expertise. We appreciate your understanding and cooperation in ensuring the safe operation of the drone.

Note* The 27000kv motor on your device is designed for high performance and may be too strong for most users. To ensure safety, the factory has set the device to only use 80% of the maximum power by default. However, if you require more power, it is possible to adjust the settings through the Betaflight software, which can be accessed under the PID tab. Please note that increasing the power beyond the default setting may increase the risk of damage to the device or injury to yourself or others, and should be done with caution.

Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the AcreoBee65 BLV4 in particular but at least we know they do distribute NewBeeDrone.

Where to buy


Wingspan: 65mm (2.6 in)
Length: 65mm (2.6 in)

Weight: 25 g (0.9 oz)
  • Drone Size: 65mm
  • Flight Controller: BeeBrain BLV4 CRSF build in VTX and Crossfire Receiver
  • Frame: Cockroach65 Brushless Frame (Solid Black Color)
  • Motors: Flow 0802 27000kv Double Ball Bearing Brushless motor
  • Propellers: Azi Tri-Blade 31mm Propeller(Jade Green Color)
  • Camera: BeeEye Camera
  • Canopy: Goober Canopy v1(Solid Black)
  • Total Weight of the Drone without battery: 24.8g

BeeBrain BLV4 CRSF Spec:

  • MCU: STM32F411
  • GYRO:BMI270
  • VTX: Switchable output power from 5mw- 25mw(for Racing) -SmartMAX(SmartMax up to 400mw)  with BeeTX 5.8Ghz Antenna
  • ESC: 12A BLHeliS Pre-Flash with Bluejay 0.18 target: S-H-40 48kHz
  • ESC Connector: JST-1.0 3Pin
  • OSD: NBD7456 Graphical OSD compatible with Betaflight OSD
  • Receiver: Crossfire Nano receiver with MINIMORTAL T Antenna
  • Flight Controller Weight: 6.5g(Include antennas and battery connector)
  • Flight Controller Size: Outer dimensions: 29x29x7.6mm
  • Flight Controller Holes: 25.5x25.5mm
  • Battery input: 1-2S (For 2S you will need to set throttle cap at less 50%)
