P-47D Thunderbolt from VQ Model

Details

The Republic P-47D Thunderbolt was a World War II era fighter aircraft produced by the United States from 1941 through 1945. Its primary armament was eight .50-caliber machine guns and in the fighter-bomber ground-attack role it could carry five-inch rockets or a bomb load of 2,500 pounds (1,103 kg). When fully loaded the P-47D weighed up to eight tons (tonnes) making it one of the heaviest fighters of the war. The P-47D was designed around the powerful Pratt & Whitney R-2800 Double Wasp engine which was also used by two U.S. Navy fighters, the Grumman F6F Hellcat and the Vought F4U Corsair. The Thunderbolt was effective as a short-to-medium range escort fighter in high-altitude air-to-air combat and ground attack in both the World War II European and Pacific theaters.

The P-47D was one of the main United States Army Air Forces (USAAF) fighters of World War II, and served with Allied air forces including France, Britain. Mexican and Brazilian squadrons fighting alongside the U.S. also flew the P-47D.

Now , VQ Introduces the P-47D.  46 – 55 size EP-GP as a super scale series ( 3S). This P-47D  comes with 2 scale flaps, 1 x painted pilots  machine gun, antena. Also we have supply in the kit some scale detail make by ply wood sothat you can make your P-47D look like a real one.
With the big battery hatch, you can use both Electric motor or Nitro engine.
As an option, the Electric retracts with scale struts are a good choise for this P-47D, it makes this P-47D became one of the best Balsa sacle warbird 46 size in the market .

Features:

  • All Balsa and lite-ply construction
  • Fully covered in weathered detail
  • Fiberglass cowling
  • Reinstalled painted pilot
  • Control surfaces pre-hinged and installed
  • Two piece wing with Aluminium Wing Joiner

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Republic P-47 Thunderbolt


Republic P-47 Thunderbolt

The Republic P-47 Thunderbolt is a World War II-era fighter aircraft produced by the American aerospace company Republic Aviation from 1941 through 1945. Its primary armament was eight .50-caliber machine guns, and in the fighter-bomber ground-attack role it could carry 5-inch rockets or a bomb load of 2,500 lb (1,100 kg). When fully loaded, the P-47 weighed up to 8 tons, making it one of the heaviest fighters of the war.

The Thunderbolt was effective as a short-to medium-range escort fighter in high-altitude air-to-air combat and ground attack in both the European and Pacific theaters. The P-47 was designed around the powerful Pratt & Whitney R-2800 Double Wasp 18-cylinder radial engine, which also powered two U.S. Navy/U.S. Marine Corps fighters, the Grumman F6F Hellcat and the Vought F4U Corsair. An advanced turbosupercharger system ensured the aircraft's eventual dominance at high altitude, while also influencing its size and design.

The P-47 was one of the main United States Army Air Forces (USAAF) fighters of World War II, and also served with other Allied air forces, including those of France, the United Kingdom, and the Soviet Union. Mexican and Brazilian squadrons fighting alongside the USAAF also flew the P-47.

The armored cockpit was relatively roomy and comfortable and the bubble canopy introduced on the P-47D offered good visibility. Nicknamed the "Jug" owing to its appearance if stood on its nose, the P-47 was noted for its firepower, as well as its ability to resist battle damage and remain airworthy. A present-day U.S. ground-attack aircraft, the Fairchild Republic A-10 Thunderbolt II, takes its name from the P-47.



This article is an extract from the Wikipedia article "Republic P-47 Thunderbolt", which is released under the Creative Commons Attribution-Share-Alike License 3.0

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series
(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the P-47D Thunderbolt in particular but at least we know they do distribute VQ Model.

Where to buy

France
Flash RC
check web site
Ship to: Europe
France
interModel
check web site
Ship to: France
Hungary
RC Hungary
check web site
Ship to: Hungary
Switzerland
Scamora
check web site
Ship to: Switzerland
France
Weymuller Modélisme
check web site
Ship to: France
Austria
DMT
check web site
Ship to: Europe
USA
Gator RC
check web site
Ship to: USA
France
Turbines RC
check web site
Ship to: Worldwide
United Kingdom
tjd Models
check web site
Ship to: United Kingdom

Wingspan: 1500mm (59.1 in)
Length: 1215mm (47.8 in)

Weight: 3300 g (7.3 lbs)
  • Wingspan:  1500mm (59.06 in.)
  • Fuselage Length:  1215mm (47.83 in.)
  • Weight (ready to fly): 3,1 - 3,3kg (6.83 - 7.28lbs) (vary with equipment in use)
  • Glow Engine:  .46-.55 (2 stroke) / .72-.82 (4 stroke)
  • Propeller: 13x6 – 15 x6
  • Electric motor: Boost 50 motor or any Electric Motor same size with .46/2 stroke engine
  • Battery: Lipo 14,8V  4500-5000 mAh
  • Radio: 6 channesl with 7 servos (2 x standard servos for elevator, rudder, and 4x Mini servo (19grams) for Aileron,Flap, Throte)

Includes:

  • Assembly instructions with stage photos
  • Tail wheel assembly
  • Fiberglass cowling
  • 1 x Fiberglass painted pilot
  • Wheels and wheels cover
  • 3 x Plastic machine gun
  • Scale detail by Ply wood
  • Engine mounts
  • Engine mounts
  • Fuel tank
  • Ply wood wing joiner
  • Decals and all hardware

Variants

VQA142DC
P-47D Thunderbolt (Camo-grey)
VQA142DT
P-47D Thunderbolt (Silver-blue)
