C-17 Globemaster 40mm from XFLY Model

Details

XFly Model is proud to announce its first transport aircraft C-17 in the EDF range. With a 1200mm wingspan, the C-17 features a scale outline and details including four efficient engines and landing gears with dual wheels. The factory pre-installed power configuration, including four 40mm fans with 1413-KV5000 brushless motors and four 20A brushless ESCs, paired with a 4S LiPo battery, delivers an abundance of thrust for vertical climbs, rolls, loops and other maneuvers. With sensible throttle management, the C-17 features a potential flight time of 3-8 minutes.

Both front and rear landing gears are fitted with dual wheels, which equips the plane with grip ability to maintain accuracy and stability while taxiing on the ground before takeoff or after landing. The battery compartment is located in the middle of the fuselage, which allows the plane to easily achieve a proper Center of Gravity. The model is conveniently sized for flying at large parks, sports fields, or traditional RC flying fields, so it can be stored and transported without disassembly. It can fit fully assembled in just about any vehicle.

Features:

  • Four efficient 40mm EDF power configuration delivering an abundance of thrust for vertical climbs, rolls, loops and other maneuvers
  • Landing gears with dual wheels designed for grip ability, accuracy and stability
  • Battery compartment reasonably designed to easily achieve a proper C.G.
  • Extended flight time of 3-8 mins when using recommended 4S 2600-4000mAh LiPo battery
  • Quick and easy assembly
  • Full painted with decal pre-applied"

Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1200mm (47.2 in)
Length: 1150mm (45.3 in)

Weight: 1560 g (3.4 lbs)
  • Wingspan: 1200 mm
  • Flight weight approx.: 1560 g
  • Control: Ailerons, Elevator, Landing Flaps, Motor Powered, Rudder
  • Length: 1150 mm
  • Rec. engine: BL Outrunner
  • Rec. Battery: 4S/2600-4000mAh LiXX
  • Airfoil: HN-354
  • Drive Type: Electric
