OV-10 Bronco 20cc from hangar 9

Details

The Hangar 9 OV-10 Bronco 30cc took the market by storm as our largest giant-scale warbird to date. However, the 108-inch wingspan made it difficult for many pilots to store and transport. The OV-10 Bronco 20cc is a scaled-down version with an 84-inch wingspan that still offers a giant-scale experience but in a more practical size for everyday flying. The three-piece wing makes it possible to remove just the outer panels to transport the center section including the fuselage, booms, and stabilizer with the landing gear extended or retracted. Or you can remove a few more screws to transport and store all of the sections separately. The smaller size also makes it compatible with more affordable and popular 20cc engines and 6S electric power systems.

Like the larger model, this version also features lightweight but strong and long-lasting built-up wood construction. The factory-applied UltraCote film covering and matching painted parts replicate the finish found on the OV-10 aircraft flown by CAL FIRE. And the included decals allow you to personalize your model by applying the nose, N-number, and city name you choose. A variety of details including a pitot tube, antennas, cockpit details, a pilot figure, and more add to the scale finish. Plus, the included electric retractable landing gear set with shock-absorbing and trailing-link struts enhances the scale experience. And it all adds up to deliver a unique and versatile scale model that’s a great choice for more experienced pilots!

Features:

  • Cockpit details including a painted pilot figure, seats, and instrument panels
    Features other scale details including a nose light, pitot tube, antennas, and more
  • 3-piece wing with center section landing gear support for easy transportation and field assembly
  • Functional 4-panel flaps enhance the scale flying experience
  • Designed to fit 20cc gas engines or equivalent 6S compatible electric power systems
  • Includes an electric retract set with shock-absorbing, trailing-link struts
  • Large top hatch for easy access to batteries and electronics
  • Complete hardware set included

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the OV-10 Bronco 20cc in particular but at least we know they do distribute hangar 9.

Wingspan: 2129mm (83.8 in)
Length: 2159mm (85 in)

Weight: 13100 g (28.9 lbs)
  • LiPo Compatibility: 6S
  • Recommended Motor Battery: SPMX50006S30
  • Spinner Size: 70 mm (2.75")
  • Minimum Required Radio: 10+ Channel full-range
  • Approximate Assembly Time: 20+ Hours
  • Flaps: Yes
  • Material: Wood
  • Retracts: Included
  • Connector Type: IC5
  • Engine Size: 20cc gas or equivalent electric power system
  • Motor Size: 5055
  • Product Length: 2159 mm (85")
  • Weight: 10.9-13.1 kg (24-29 lbs)
  • Motor Type: Brushless
  • Speed Control: Included
  • Wingspan: 2129 mm (83.8")
