Nazgul XL10 V6 S from iFlight

Details

The XL10 V6 6S Analog is a 10" BNF quadcopter that comes with the BLITZ Whoop 1.6W VTX Video Transmission System, and HQ  10" 3-Blade  propellers. The XL10 V6 has been pre-tuned and set up with everything you need, all you need to do is bind-and-fly! Loaded with lots of power; it comes with the XING2 3110motors, BLITZ F7 Flight Controller, and the BLITZ E55 4-IN-1 ESC, which make this quad a must-have!

The XL10 V6 BNF fly is balanced because of the true X configuration and wide stance. These main changings make flight stable in the air.

Features:

  • Full 3K Carbon Fiber airframe
  • Popular True-X configuration
  • Big size XING2 3110 with extreme lift and flight performance
  • GPS module pre-installed (BF GPS rescue or INAV GPS RTH feature available)

Pictures

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s/XE Ethos
FrSky X18/X18s/TWIN Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Nazgul XL10 V6 S in particular but at least we know they do distribute iFlight.

Wingspan: 297mm (11.7 in)
Length: 297mm (11.7 in)

Weight: 860 g (1.9 lbs)
  • FC: BLITZ F722 Flight Controller
  • ESC: BLITZ E55 4-IN-1 2-6S 55A ESC
  • Video Transmission: BLITZ Whoop 1.6W VTX
  • Frame: 420mm wheelbase
  • Motor: XING2 3110 900KV motors
  • Prop: 10X4.5X3 propellers
  • Weight: 860g (Without Battery)
  • Dimensions (L×W×H):297x297x35mm
  • Max Speed: 140km/h
  • Maximum Takeoff Altitude: 6000 m
  • Max Hover Time: Approx. 40 mins (with 6S2P 8000mAh no load)
  • Max Wind Speed Resistance: Level 7
  • Operating Temperature Range: -10° to 40° C (14° to 104° F)
  • Antennas: Single Antenna
  • GNSS: GPS + Galileo

Video Transmission:

  • Product Name: BLITZ 1.6W VTX
  • Output Power: 0-25-400-800-1600mw
  • Input Volts: 12V
  • Working Current: ≤pit @40mA,≤25mw@150mA,≤400mw@330mA,≤800mw@460mA,≤1600mw@660mA
  • Transmission frequencies: 40CH(A-B-E-F-R)
  • Antenna Interface: IPEX
  • Mounting Hole: 25*25/φ1.6mm
  • Weight: 16.5 grams (Without antenna and cable)
  • Dimensions: L37mm*W31.5mm*H10mm

Variants

XL10V6
Nazgul XL10 V6 S (Black Lime)
