Spitfire Mk IX from FlightLine RC

Details

FlightLine’s 1600mm wingspan Spitfire Mk.IXc is approximately 1/7 scale and an entirely larger beast with all the bells and whistles we’ve come to expect from aircraft in the 1600mm Class. This Spitfire is molded from EPO foam, featuring a scale shape and smooth surface. The main wing is assembled from hollow foam parts and an interlocking plywood and carbon fiber frame, providing lower weight and higher strength than a solid foam wing. The main wing and horizontal tail are attached with screws for very convenient transport, and proper ventilation is also designed to keep the electronics cool. The large battery hatch and removable battery bay floor provides easy access to an organized battery and receiver compartment, including space for an optional flight stabilizer gyro.

This elegant model aircraft is equipped with a 5055-390KV brushless outrunner motor, 80A ESC, and scale 4-blade propeller. With the recommended 6S 4000-5000mAh lipo battery, the Spitfire MK.IXc has a level top speed of 125kph/75mph, with tall vertical power and 6-10 minutes of flight time depending on throttle management. Delivering capable grass handling performance, the main landing gear use shock absorbing Oleo struts, a main wheel diameter of 85mm, and a tail wheel diameter of 45mm. Metal reinforcement plates, 5mm thick steel strut pins and axles, and metal trunions work together with the suspension struts and soft wheels to dampen the forces caused by operating this aircraft on rough runways. The FlightLine RC 1600mm Spitfire Mk.IXc was optimized for sport scale performance, gentle handling, and an almost effortless flying experience, suitable for intermediate pilots and above. Importantly, a very predictable stall and power on recovery make the aircraft easy to control throughout all stages of flight. Day-Bright LEDs also aid in visibility of this large and beautiful foam electric model aircraft.

Features

  • Grass capable landing gear with suspension struts and 5mm thick steel pin and metal trunion
  • Scale four panel split flaps
  • Big 16x10 Propeller, 5055-390KV brushless motor and 80A ESC with EC5 connector
  • LED wingtip lights and dorsal signal light
  • 17g digital hybrid servos, brass ball links, and nylon hinges on all control surfaces
  • Machine Screw Inserts molded into the spinner backplate to easily adjust blade tracking while mounted on the motor
  • Removable wings, cannon, and antenna for easy transport
  • Central Control Board for organized wiring
  • Access holes to adjust Elevator/Rudder linkages without removing the wing
  • Gyro ready plywood area near CG location
  • Two decal sets included: MA621 DV-A, Squadron Leader Tony Gaze, 129 Squadron, 1943 and BS393 GW-Z for Lt. Michel Boudier, 340 Squadron, 1942

Pictures

Manual

Radio icons

(Click on the icon you want to download)
FrSky X20/X20s Ethos
FrSky Horus OpenTx
FrSky Horus FrOs
Standard
Silhouette
FrSky X9D/X9D+/X9E
Spektrum IX12 & IX20
Futaba 18MZ
Jeti DS-24
Graupner MZ-16 & MZ-32
Radiomaster TX16S
Jumper T16 & T18 series

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the Spitfire Mk IX in particular but at least we know they do distribute FlightLine RC.

Where to buy

Netherlands
Motion RC B.V.
check web site
Ship to: Europe
USA
Motion RC LLC
check web site
Ship to: USA

Wingspan: 1600mm (63 in)
Length: 1350mm (53.1 in)

Weight: 2850 g (6.3 lbs)
Wingspan 1600mm / 62.99in
Length 1350mm / 53.1in
Flying Weight 2850g / 100.53oz
CG (Center of Gravity) 90mm from the leading edge of the wing at the root
Power System 5055-390KV Brushless Outrunner Motor
Electronic Speed Control 80A Brushless with EC5 connector
Propeller / EDF 16x10 4 Blade Propeller
Servos 17g digital hybrid gear standard with 550mm lead: left aileron, right aileron
17g digital hybrid gear standard with 300mm lead (plus 100mm extension): left flap, right flap
17g digital hybrid gear standard with 300mm lead: elevator, rudder
Landing Gear Electric retracts with metal trunions
Required Battery 6 Cell 22.2V 4000 to 6000 mAh LiPo battery with EC5 Connector
Required Radio 6+ Channel 2.4GHz

Variants

LW303P
Spitfire Mk IX (Camo-military)
