MOZ7 V2 O4 Pro from GEPRC

Details

The MOZ7 V2 marks a significant upgrade, now featuring the DJI O4 Air Unit Pro. This integration brings a 1/1.3-inch image sensor for superior low-light performance and wider dynamic range, alongside a 155° ultra-wide field of view perfect for high-speed, low-altitude flights. Pilots will experience pristine video transmission at 1080p/100fps (H.265), with onboard recording supporting up to 4K/120fps. The transmission range is extended to an impressive 15 km, and the 10-bit D-Log M color mode ensures stunning visual fidelity for an incredibly immersive FPV experience.

Beyond its advanced imaging, the MOZ7 V2 boasts numerous optimizations. These include a reinforced frame, a more centered center of gravity, and a 7075 aerospace aluminum camera protector for enhanced durability and clear FPV footage free of propellers. Equipped with the H743 flight controller, GEP-M1025 GPS, and an ELRS 915M/2.4G Gemx dual-band receiver, the MOZ7 V2 guarantees reliable long-range performance. It also offers flexible mounting with two options for both action cameras and batteries.

The MOZ7 V2 delivers an unmatched flying and creative experience, setting a new standard for immersive FPV visuals.

AIR-RC/SkyRaccoon Note: The antennas were deliberately reduced in size to make the drone appear larger in the icons

Pictures

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.

We cannot guarantee that the shops listed below do sell the MOZ7 V2 O4 Pro in particular but at least we know they do distribute GEPRC.

Wingspan: 336mm (13.2 in)
Length: 336mm (13.2 in)

Weight: 750 g (1.7 lbs)
  • Model: GEPRC MOZ7 V2 O4 Pro
  • Frame: GEP-MOZ7 V2
  • Wheelbase: 336mm
  • Top Plate Thickness: 2.5mm
  • Base Plate Thickness: 2.5mm
  • Middle Plate Thickness: 3mm
  • Arms Thickness: 6mm
  • FC: TAKER H743 BT
  • MCU: STM32H743
  • Gyroscope: MPU6000&42688-P dual
  • Barometer: Yes
  • GPS: GEP-M1025
  • OSD: BetaFlight OSD w/ AT7456E chip
  • ESC: TAKER H65_8S_32Bit 65A 4IN1 ESC
  • VTX: DJI O4 Air Unit Pro Air Unit module
  • Camera: DJI O4 Air Unit Pro camera module
  • Antenna: Momoda2-SMA-LHCP right rotate-RG141 black wire- 170mm- inner threads
  • Power Connector: XT60E-M
  • Motor: SPEEDX2 2809 1280KV V1.1
  • Prop: HQ 7.5*3.7*3 3-blade_transparent grey
  • Version Weight: HD 750±10g
  • Receiver: PNP / ELRS 915M/2.4G GemX / TBSNanoRX
  • Recommended Battery: LiPo 6S 3300mAh / Lilon 8000mAh
  • Flight Time: 25 mins (Tested at slow cruising speeds; the actual may vary due to product differences, firmware version, flying style, and environment.)
