RC Factory Ares XL

Radio-Controlled Plane for RC Pilots

Details

Ares XL was developed based on the successful Ares Indoor platform, originally created in cooperation with Krill Aircraft and Jack Jehle. With the XL version, we pushed the concept even further – resulting in a larger outdoor model with a fully airfoiled wing that delivers an entirely new flying experience and characteristics much closer to real large-scale fighter aircraft.

Designed specifically for outdoor flying, the airfoiled wing provides significantly improved flight characteristics compared to the indoor version. The aircraft feels exceptionally stable, precise, and predictable in all conditions. The wing profile adds confidence in turns, improved energy retention during fast passes, and an overall more mature and realistic flight behavior.

One of the things that impressed us the most during development was the incredible wind resistance. Ares XL remains calm and precise even in conditions where typical EPP models start losing stability. In the air, it feels smooth, confident, and highly realistic — behaving much more like a larger composite fighter aircraft than a traditional foam model.

The construction combines low weight with high strength and durability. The EPP material offers excellent crash resistance and easy repairability, even after harder landings or minor impacts. At the same time, the model remains agile and dynamic while preserving a stable and accurate flying feel.

Ares XL is the result of extensive development with one clear goal — to create a durable, precise, and exceptionally capable EPP aircraft that delivers the feeling of flying a large fighter jet in a compact and practical form.

Pictures

Manual


If the Manual doesn't show you can click here to open the document in a new window.

Radio icons

FrSky X10

FrSky X12s

Jumper T16

Jumper T18

Radiomaster TX16S

FlySky NV14

FlySky EL18

PNG (192x114)

FrSky X9D

FrSky X9E

BMP (64x32)

BMP (64x32)

FrSky X20

FrSky X20 Pro

FrSky XE

Kavan V20

PNG (300x280)

BMP Recommended (300x280)

FrSky X18

FrSky Twin

PNG (180x166)

BMP Recommended (180x166)

FrSky X10

FrSky X12s

PNG (180x160)

BMP Recommended (180x160)

FrSky X10

FrSky X12s

JPG (155x100)

Futaba 18MZ

JPG (158x80)

Graupner MZ16

Graupner MZ32

BMP (158x106)

Jeti DS-24

PNG (320x240)

Spektrum ix12

Spektrum ix20

JPG (266x164)

Similar Models

Some content in menu 2.


Wingspan: 1000mm (39.4 in)
Length: 1120mm (44.1 in)

Weight: 400 g (14.1 oz)
  • Wingspan: 1000 mm (39.37 in)
  • Length: 1120 mm (44.09 in)
  • All-Up Weight (AUW): 330 – 400 g (11.6 – 14.1 oz)
  • Motor: Brushless 2807 / 1700KV
  • ESC: 30 A
  • Servos: 4 × D10M
  • Battery: 850 – 1300 mAh LiPo, 3–4S
  • Propeller: 6" (152 mm)

Other Variant(s)
